CARTER 33
Built by Olympic Yachts (GRE)
• Designed by Dick Carter
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Number Built:
200
Dimensions
Length Overall (LOA):
9.93 m
Length Waterline (LWL):
7.11 m
Beam:
3.35 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
3,402 kg
Ballast:
1,297 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
22.28 m²
Mainsail Area:
15.32 m²
Total Sail Area (calculated):
37.60 m²
Sail Area (reported):
37.63 m²
I (Fore Triangle Height):
11.89 m
J (Fore Triangle Base):
3.75 m
P (Mainsail Hoist):
10.36 m
E (Boom Length):
2.96 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD6A
Engine Power:
10 HP
Fuel Capacity:
42 L
Water Capacity:
401 L
Performance Ratios
Hull Speed:
6.47 knots
SA/Displacement (Calculated):
16.62
SA/Displacement (Reported):
16.97
Ballast/Disp Ratio:
38.13%
Displacement/Length:
263.68
Comfort Ratio:
18.21
Capsize Screening:
2.25
S-Number:
2.04
Notes
Along with the CARTER 30, the CARTER 33 is one of the most popular of the designers 'series built' boats. They were available through his company Carter Offshore and built primarily in Greece.
