CARINA
Built by Marina-Werft (GER)
• Designed by Günther Thomat
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
Wood or FG
First Built:
1962
Last Built:
1980
Number Built:
1500
Dimensions
Length Overall (LOA):
5.96 m
Length Waterline (LWL):
4.77 m
Beam:
2.11 m
Draft (Max):
0.90 m
Max Height:
6.85 m
Weight & Ballast
Displacement:
850 kg
Ballast:
240 kg
Sail Plan
Sail Area (reported):
16.10 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.30 knots
SA/Displacement (Reported):
18.28
Ballast/Disp Ratio:
28.23%
Displacement/Length:
218.26
Comfort Ratio:
13.08
Capsize Screening:
2.25
Notes
In the late 1960s and 1970s the Carina was a very successful model and one of the most popular pocket cruisers in Germany. First built in plywood with a hard chine, beginning in 1966 the boats were built using FG and offered with either a hard chine or rounded frame. In 1968, hulls were only built with a round-frame with keel, twin keel or keel-centreboard. In the 1970s also built with forecastle deck.
