CARBON 32
Built by Columbia Yachts/One Design Composits
• Designed by Tim Kernan
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
Construction:
Carbon fiber
First Built:
2011
Dimensions
Length Overall (LOA):
9.75 m
Length Waterline (LWL):
8.23 m
Beam:
3.09 m
Draft (Max):
2.29 m
Draft (Min):
0.66 m
Weight & Ballast
Displacement:
1,996 kg
Ballast:
806 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.57 m²
Mainsail Area:
26.25 m²
Total Sail Area (calculated):
47.82 m²
Sail Area (reported):
47.57 m²
I (Fore Triangle Height):
11.26 m
J (Fore Triangle Base):
3.83 m
P (Mainsail Hoist):
11.58 m
E (Boom Length):
4.53 m
Engine & Systems
Performance Ratios
Hull Speed:
6.96 knots
SA/Displacement (Calculated):
30.16
SA/Displacement (Reported):
30.59
Ballast/Disp Ratio:
40.36%
Displacement/Length:
99.80
Comfort Ratio:
10.92
Capsize Screening:
2.48
S-Number:
6.29
Notes
Updated version (2011) of the Columbia 32 Sport Yacht.
