CAPRI 26-1 (CHRIS-CRAFT)
Built by Chris-Craft (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG (solid)
First Built:
1965
Last Built:
1967
Number Built:
90
Dimensions
Length Overall (LOA):
8.00 m
Length Waterline (LWL):
5.79 m
Beam:
2.49 m
Draft (Max):
1.22 m
Max Height:
10.33 m
Weight & Ballast
Displacement:
1,778 kg
Ballast:
862 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
14.64 m²
Mainsail Area:
13.49 m²
Total Sail Area (calculated):
28.13 m²
Sail Area (reported):
28.15 m²
I (Fore Triangle Height):
9.51 m
J (Fore Triangle Base):
3.08 m
P (Mainsail Hoist):
8.05 m
E (Boom Length):
3.35 m
Engine & Systems
Engine Type:
Outboard
Water Capacity:
68 L
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calculated):
19.17
SA/Displacement (Reported):
19.55
Ballast/Disp Ratio:
48.47%
Displacement/Length:
255.14
Comfort Ratio:
17.43
Capsize Screening:
2.08
S-Number:
2.35
Notes
S&S design #1771.1
