CAPE NORTH 43
Built by Cape Yachts (HK)
• Designed by Ted Brewer
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Staysail Ketch
Construction:
FG
First Built:
1977
Dimensions
Length Overall (LOA):
13.18 m
Length Waterline (LWL):
10.77 m
Beam:
3.86 m
Draft (Max):
1.92 m
Draft (Min):
0.67 m
Weight & Ballast
Displacement:
11,340 kg
Ballast:
5,080 kg
Sail Plan
Foresail Area:
44.88 m²
Mainsail Area:
30.11 m²
Total Sail Area (calculated):
74.99 m²
Sail Area (reported):
74.97 m²
I (Fore Triangle Height):
16.09 m
J (Fore Triangle Base):
5.58 m
P (Mainsail Hoist):
14.11 m
E (Boom Length):
4.27 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Model:
M50B
Fuel Capacity:
341 L
Water Capacity:
681 L
Performance Ratios
Hull Speed:
7.96 knots
SA/Displacement (Calculated):
14.86
SA/Displacement (Reported):
15.16
Ballast/Disp Ratio:
44.80%
Displacement/Length:
253.08
Comfort Ratio:
34.87
Capsize Screening:
1.74
S-Number:
1.97
Notes
This from designer, Ted Brewer: "The yacht is a grp version of the custom, wood, 'Black Velvet' (see her on www.tedbrewer.com under Sail - Wood.). The first fibreglass versions were built by Cape North in Hong Kong, in the mid '70s, as the Cape North 43. Later a Philippine firm obtained the molds and produced a few.
