CAPE DORY 36
Built by Cape Dory Yachts (USA)
• Designed by Carl Alberg
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1978
Last Built:
1990
Number Built:
166
Dimensions
Length Overall (LOA):
11.01 m
Length Waterline (LWL):
8.23 m
Beam:
3.25 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
7,303 kg
Ballast:
2,744 kg
Sail Plan
Foresail Area:
30.24 m²
Mainsail Area:
27.50 m²
Total Sail Area (calculated):
57.74 m²
Sail Area (reported):
57.79 m²
I (Fore Triangle Height):
12.80 m
J (Fore Triangle Base):
4.72 m
P (Mainsail Hoist):
11.28 m
E (Boom Length):
4.88 m
Engine & Systems
Engine Type:
Diesel
Fuel Capacity:
163 L
Water Capacity:
500 L
Performance Ratios
Hull Speed:
6.96 knots
SA/Displacement (Calculated):
15.34
SA/Displacement (Reported):
15.67
Ballast/Disp Ratio:
37.58%
Displacement/Length:
365.16
Comfort Ratio:
35.74
Capsize Screening:
1.69
S-Number:
1.23
Notes
A similar boat was later sold as the ROBINHOOD 36.
