ALDEN 43
Built by Alden Yachts Inc. (USA)
• Designed by Niels Helleberg
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1992
Last Built:
1997
Dimensions
Length Overall (LOA):
13.16 m
Length Waterline (LWL):
10.52 m
Beam:
3.81 m
Draft (Max):
2.26 m
Weight & Ballast
Displacement:
9,979 kg
Ballast:
4,536 kg
Sail Plan
Foresail Area:
44.67 m²
Mainsail Area:
41.46 m²
Total Sail Area (calculated):
86.13 m²
Sail Area (reported):
86.12 m²
I (Fore Triangle Height):
17.98 m
J (Fore Triangle Base):
4.97 m
P (Mainsail Hoist):
15.54 m
E (Boom Length):
5.33 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Model:
63-B
Engine Power:
63 HP
Fuel Capacity:
189 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.87 knots
SA/Displacement (Calculated):
18.58
SA/Displacement (Reported):
18.96
Ballast/Disp Ratio:
45.45%
Displacement/Length:
239.18
Comfort Ratio:
31.71
Capsize Screening:
1.79
S-Number:
2.47
Notes
Alden design #1215. (with traditional or reverse transom).
