ALDEN 44
Built by Alden Yachts/Tillotson Pearson (USA)
• Designed by Alden Associates/Nils Helleberg
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Cutter
Construction:
FG
First Built:
1976
Last Built:
1991
Number Built:
40
Dimensions
Length Overall (LOA):
13.46 m
Length Waterline (LWL):
10.39 m
Beam:
3.81 m
Draft (Max):
2.67 m
Draft (Min):
1.50 m
Weight & Ballast
Displacement:
11,113 kg
Ballast:
4,536 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
48.50 m²
Mainsail Area:
32.38 m²
Total Sail Area (calculated):
80.88 m²
Sail Area (reported):
80.92 m²
I (Fore Triangle Height):
16.49 m
J (Fore Triangle Base):
5.88 m
P (Mainsail Hoist):
14.36 m
E (Boom Length):
4.51 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Fuel Capacity:
341 L
Water Capacity:
606 L
Performance Ratios
Hull Speed:
7.82 knots
SA/Displacement (Calculated):
16.24
SA/Displacement (Reported):
16.59
Ballast/Disp Ratio:
40.82%
Displacement/Length:
276.32
Comfort Ratio:
35.31
Capsize Screening:
1.72
S-Number:
1.90
Notes
Alden design #1036xx.
