CALIBER 38
Built by Caliber Yachts (USA)
• Designed by Michael McCreary
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1987
Dimensions
Length Overall (LOA):
11.58 m
Length Waterline (LWL):
9.75 m
Beam:
3.86 m
Draft (Max):
1.50 m
Weight & Ballast
Displacement:
8,391 kg
Ballast:
4,082 kg
Sail Plan
Foresail Area:
37.53 m²
Mainsail Area:
28.22 m²
Total Sail Area (calculated):
65.75 m²
Sail Area (reported):
65.78 m²
I (Fore Triangle Height):
15.39 m
J (Fore Triangle Base):
4.88 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
4.11 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
4JHBE
Engine Power:
44 HP
Fuel Capacity:
174 L
Water Capacity:
591 L
Performance Ratios
Hull Speed:
7.58 knots
SA/Displacement (Calculated):
15.92
SA/Displacement (Reported):
16.26
Ballast/Disp Ratio:
48.65%
Displacement/Length:
252.04
Comfort Ratio:
28.75
Capsize Screening:
1.92
S-Number:
2.08
Notes
Shoal draft: 4.5'/1.4m.
