CAL 43
Built by Jensen Marine (USA)
• Designed by C. William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Last Built:
1972
Number Built:
14
Dimensions
Length Overall (LOA):
13.00 m
Length Waterline (LWL):
9.91 m
Beam:
3.51 m
Draft (Max):
1.98 m
Weight & Ballast
Displacement:
9,072 kg
Ballast:
3,629 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
41.45 m²
Mainsail Area:
35.87 m²
Total Sail Area (calculated):
77.32 m²
Sail Area (reported):
77.30 m²
I (Fore Triangle Height):
15.85 m
J (Fore Triangle Base):
5.23 m
P (Mainsail Hoist):
13.84 m
E (Boom Length):
5.18 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Fuel Capacity:
151 L
Water Capacity:
265 L
Performance Ratios
Hull Speed:
7.64 knots
SA/Displacement (Calculated):
17.78
SA/Displacement (Reported):
18.14
Ballast/Disp Ratio:
40.00%
Displacement/Length:
260.09
Comfort Ratio:
33.62
Capsize Screening:
1.70
S-Number:
2.18
Notes
A relatively rare Cal model that was in production for less than a year.
