CAL 36
Built by Jensen Marine (USA)
• Designed by C. William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1966
Dimensions
Length Overall (LOA):
10.82 m
Length Waterline (LWL):
8.23 m
Beam:
3.15 m
Draft (Max):
1.74 m
Weight & Ballast
Displacement:
5,080 kg
Ballast:
2,041 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.29 m²
Mainsail Area:
27.49 m²
Total Sail Area (calculated):
55.78 m²
Sail Area (reported):
55.74 m²
I (Fore Triangle Height):
12.80 m
J (Fore Triangle Base):
4.42 m
P (Mainsail Hoist):
11.06 m
E (Boom Length):
4.97 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
114 L
Water Capacity:
303 L
Performance Ratios
Hull Speed:
6.96 knots
SA/Displacement (Calculated):
18.87
SA/Displacement (Reported):
19.24
Ballast/Disp Ratio:
40.18%
Displacement/Length:
254.03
Comfort Ratio:
26.12
Capsize Screening:
1.85
S-Number:
2.34
Notes
Thanks to 'adelie' for providing correction.
