CAL 22
Built by Bangor Punta Marine (USA)
• Designed by C. R. Hunt Assoc.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1984
Last Built:
1997
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
5.94 m
Beam:
2.36 m
Draft (Max):
1.07 m
Weight & Ballast
Displacement:
953 kg
Ballast:
352 kg
Sail Plan
Foresail Area:
9.60 m²
Mainsail Area:
11.15 m²
Total Sail Area (calculated):
20.75 m²
Sail Area (reported):
20.72 m²
I (Fore Triangle Height):
7.50 m
J (Fore Triangle Base):
2.56 m
P (Mainsail Hoist):
7.86 m
E (Boom Length):
2.83 m
Engine & Systems
Performance Ratios
Hull Speed:
5.92 knots
SA/Displacement (Calculated):
21.42
SA/Displacement (Reported):
21.81
Ballast/Disp Ratio:
36.90%
Displacement/Length:
126.44
Comfort Ratio:
10.47
Capsize Screening:
2.42
S-Number:
4.46
Notes
Shoal Draft version.
