CAL 2-30
Built by Jensen Marine (USA)
• Designed by C. William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1968
Last Built:
1972
Number Built:
204
Dimensions
Length Overall (LOA):
9.20 m
Length Waterline (LWL):
7.62 m
Beam:
2.74 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
4,672 kg
Ballast:
2,041 kg
Sail Plan
Foresail Area:
21.19 m²
Mainsail Area:
21.95 m²
Total Sail Area (calculated):
43.14 m²
Sail Area (reported):
43.11 m²
I (Fore Triangle Height):
11.28 m
J (Fore Triangle Base):
3.76 m
P (Mainsail Hoist):
10.67 m
E (Boom Length):
4.11 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Performance Ratios
Hull Speed:
6.70 knots
SA/Displacement (Calculated):
15.44
SA/Displacement (Reported):
15.74
Ballast/Disp Ratio:
43.69%
Displacement/Length:
294.29
Comfort Ratio:
32.10
Capsize Screening:
1.66
S-Number:
1.69
Notes
Although all were designed by Lapworth, the CAL 2-30 is completely different from the earlier CAL 30, and the later CAL 3-30.
