CAL 2-27
Built by Bangor Punta Marine (USA)
• Designed by William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1974
Last Built:
1980
Number Built:
656
Dimensions
Length Overall (LOA):
8.10 m
Length Waterline (LWL):
6.73 m
Beam:
2.82 m
Draft (Max):
1.30 m
Headroom:
1.85 m
Max Height:
12.12 m
Weight & Ballast
Displacement:
3,039 kg
Ballast:
1,406 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
20.07 m²
Mainsail Area:
14.74 m²
Total Sail Area (calculated):
34.81 m²
Sail Area (reported):
34.75 m²
I (Fore Triangle Height):
10.97 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
9.39 m
E (Boom Length):
3.14 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Model:
Atomic 11
Engine Power:
11 HP
Fuel Capacity:
57 L
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.30 knots
SA/Displacement (Calculated):
16.59
SA/Displacement (Reported):
16.89
Ballast/Disp Ratio:
46.27%
Displacement/Length:
277.86
Comfort Ratio:
22.83
Capsize Screening:
1.97
S-Number:
1.92
Notes
The second in a series of 3 different CAL 27's, all designed by Lapworth. A Farymann diesel was offered on later models. A boat of the same design called the CROWN 28 was built in Canada.
