CAL 2-25
Built by Bangor Punta Marine (USA)
• Designed by C. William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1977
Last Built:
1983
Number Built:
392
Dimensions
Length Overall (LOA):
7.70 m
Length Waterline (LWL):
6.71 m
Beam:
2.74 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
2,041 kg
Ballast:
907 kg
Sail Plan
Foresail Area:
16.86 m²
Mainsail Area:
12.36 m²
Total Sail Area (calculated):
29.22 m²
Sail Area (reported):
29.17 m²
I (Fore Triangle Height):
10.06 m
J (Fore Triangle Base):
3.35 m
P (Mainsail Hoist):
8.53 m
E (Boom Length):
2.90 m
Engine & Systems
Water Capacity:
79 L
Performance Ratios
Hull Speed:
6.29 knots
SA/Displacement (Calculated):
18.16
SA/Displacement (Reported):
18.48
Ballast/Disp Ratio:
44.44%
Displacement/Length:
188.67
Comfort Ratio:
16.21
Capsize Screening:
2.18
S-Number:
3.03
Notes
Sometimes referred to as CAL 25-2 or CAL 25 MKII.
