CABO RICO 38
Built by Cabo Rico Custom Yachts, Inc. (CR)
• Designed by W.I.B. Crealock/Dennis Garrett
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1977
Number Built:
200
Dimensions
Length Overall (LOA):
11.58 m
Length Waterline (LWL):
8.92 m
Beam:
3.51 m
Draft (Max):
1.52 m
Max Height:
15.24 m
Weight & Ballast
Displacement:
9,525 kg
Ballast:
3,538 kg
Sail Plan
Foresail Area:
37.81 m²
Mainsail Area:
29.32 m²
Total Sail Area (calculated):
67.13 m²
Sail Area (reported):
90.02 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
5.64 m
P (Mainsail Hoist):
12.22 m
E (Boom Length):
4.80 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4108
Fuel Capacity:
208 L
Water Capacity:
568 L
Performance Ratios
Hull Speed:
7.25 knots
SA/Displacement (Calculated):
14.94
SA/Displacement (Reported):
20.45
Ballast/Disp Ratio:
37.14%
Displacement/Length:
374.62
Comfort Ratio:
39.37
Capsize Screening:
1.67
S-Number:
1.16
Notes
S.A. (reported) above =
