C-YACHT 1040
Built by Zaadnoordijk Watersport (NED)
• Designed by Frans Maas
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
GRP
First Built:
2003
Dimensions
Length Overall (LOA):
10.40 m
Length Waterline (LWL):
8.30 m
Beam:
3.47 m
Draft (Max):
1.50 m
Headroom:
1.90 m
Max Height:
15.00 m
Weight & Ballast
Displacement:
5,500 kg
Ballast:
2,200 kg
Ballast Type:
Cast iron
Sail Plan
Foresail Area:
23.60 m²
Mainsail Area:
23.20 m²
Total Sail Area (calculated):
46.80 m²
Sail Area (reported):
57.70 m²
I (Fore Triangle Height):
12.55 m
J (Fore Triangle Base):
3.76 m
P (Mainsail Hoist):
11.60 m
E (Boom Length):
4.00 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel; Saildrive
Engine Power:
27 HP
Fuel Capacity:
100 L
Water Capacity:
200 L
Performance Ratios
Hull Speed:
6.99 knots
SA/Displacement (Calculated):
15.02
SA/Displacement (Reported):
18.89
Ballast/Disp Ratio:
40.00%
Displacement/Length:
268.10
Comfort Ratio:
25.08
Capsize Screening:
1.98
S-Number:
1.86
Notes
Optional lead keel. Ballast: 2,480 kg / 5,467.5 lbs; Draft: 1.75 m / 5.75 ft
