ALBERG 37
Built by Whitby Boat Works Ltd. (CAN)
• Designed by Carl Alberg
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1967
Last Built:
1988
Number Built:
248
Dimensions
Length Overall (LOA):
11.33 m
Length Waterline (LWL):
8.08 m
Beam:
3.10 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
7,620 kg
Ballast:
2,948 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.78 m²
Mainsail Area:
31.30 m²
Total Sail Area (calculated):
60.08 m²
Sail Area (reported):
60.02 m²
I (Fore Triangle Height):
13.49 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
11.73 m
E (Boom Length):
5.33 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD2B
Engine Power:
23 HP
Fuel Capacity:
132 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
6.90 knots
SA/Displacement (Calculated):
15.51
SA/Displacement (Reported):
15.82
Ballast/Disp Ratio:
38.69%
Displacement/Length:
403.02
Comfort Ratio:
39.80
Capsize Screening:
1.59
S-Number:
1.05
Notes
The Mark I was built between 1967 - 1971.
