C&C 34
Built by C&C Yachts
• Designed by Rob Ball
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1977
Dimensions
Length Overall (LOA):
10.21 m
Length Waterline (LWL):
7.90 m
Beam:
3.35 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
4,581 kg
Ballast:
1,860 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.61 m²
Mainsail Area:
19.40 m²
Total Sail Area (calculated):
48.01 m²
Sail Area (reported):
48.03 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
11.66 m
E (Boom Length):
3.33 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
76 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
6.82 knots
SA/Displacement (Calculated):
17.41
SA/Displacement (Reported):
17.76
Ballast/Disp Ratio:
40.59%
Displacement/Length:
258.92
Comfort Ratio:
22.71
Capsize Screening:
2.04
S-Number:
2.16
Notes
Deep keel: 6.4'/1.95m
