SURPRISE 45
Built by Ta Yang Yacht Building Co. (TAIWAN)
• Designed by Pieter Beeldsnijder
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Ketch
First Built:
1981
Dimensions
Length Overall (LOA):
14.00 m
Length on Deck (LOD):
13.11 m
Length Waterline (LWL):
10.84 m
Beam:
4.09 m
Draft (Max):
1.96 m
Headroom:
1.93 m
Max Height:
17.47 m
Weight & Ballast
Displacement:
11,975 kg
Ballast:
5,000 kg
Sail Plan
Sail Area (reported):
85.38 m²
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4.108
Engine Power:
51 HP
Fuel Capacity:
322 L
Water Capacity:
644 L
Performance Ratios
Hull Speed:
7.99 knots
SA/Displacement (Reported):
16.65
Ballast/Disp Ratio:
41.75%
Displacement/Length:
261.66
Comfort Ratio:
33.21
Capsize Screening:
1.81
Immersion:
305 kg/cm
Notes
We're told the first boats were built in Aluminum in the Netherlands before a plug was made for fiberglass construction by Ta Yang in Taiwan.
