RANGER 33
Built by Ranger Yachts/Bangor Punta (USA)
• Designed by Gary Mull
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1969
Last Built:
1978
Number Built:
464
Dimensions
Length Overall (LOA):
10.11 m
Length Waterline (LWL):
8.00 m
Beam:
2.92 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
4,763 kg
Ballast:
2,041 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
26.74 m²
Mainsail Area:
22.36 m²
Sail Area:
49.09 m²
Sail Area (reported):
49.15 m²
I (Fore Triangle Height):
12.65 m
J (Fore Triangle Base):
4.23 m
P (Mainsail Hoist):
10.67 m
E (Boom Length):
4.19 m
Est. Forestay Length:
13.34 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
79 L
Water Capacity:
79 L
Performance Ratios
Hull Speed:
6.87 knots
SA/Displacement (Calc):
17.69
SA/Displacement (Reported):
17.71
Ballast/Disp Ratio:
42.86%
Displacement/Length:
259.15
Comfort Ratio:
28.24
Capsize Screening:
1.75
S-Number:
2.15
Immersion:
160 kg/cm
Notes
On later boats, wheel steering became standard and a Universal diesel was offered as an option.
