R.N.S.A. TWENTY-FOUR
Built by Camper & Nicholson
• Designed by Laurent Giles
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Fractional Sloop
First Built:
1947
Number Built:
15
Dimensions
Length Overall (LOA):
9.75 m
Length Waterline (LWL):
7.32 m
Beam:
2.29 m
Draft (Max):
1.62 m
Weight & Ballast
Displacement:
4,377 kg
Sail Plan
Foresail Area:
17.17 m²
Mainsail Area:
19.48 m²
Sail Area:
36.65 m²
Sail Area (reported):
36.70 m²
I (Fore Triangle Height):
9.39 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
10.39 m
E (Boom Length):
3.75 m
Est. Forestay Length:
10.08 m
Engine & Systems
Performance Ratios
Hull Speed:
6.56 knots
SA/Displacement (Calc):
13.97
SA/Displacement (Reported):
13.99
Displacement/Length:
311.63
Comfort Ratio:
38.56
Capsize Screening:
1.41
S-Number:
1.43
Immersion:
115 kg/cm
Notes
RNSA = Royal Naval Sailing Association. One of the first 'offshore one-designs' and the brainchild of Capt. J.H. Illingworth. His own 'Minx of Malham', the first of this design, proved itself in it first season by taking the RORC small-class championships of 1949.
