QUICKSTEP 24
Built by Stannard Boat Works/C.E. Ryder/Shannon Yachts
• Designed by Ted Brewer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1976
Last Built:
1989
Number Built:
200
Dimensions
Length Overall (LOA):
7.29 m
Length Waterline (LWL):
5.79 m
Beam:
2.41 m
Draft (Max):
1.03 m
Weight & Ballast
Displacement:
1,814 kg
Ballast:
862 kg
Ballast Type:
Cast lead
Sail Plan
Foresail Area:
12.49 m²
Mainsail Area:
11.61 m²
Sail Area:
24.10 m²
Sail Area (reported):
24.06 m²
I (Fore Triangle Height):
8.63 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
7.62 m
E (Boom Length):
3.05 m
Est. Forestay Length:
9.10 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
16.52
SA/Displacement (Reported):
16.49
Ballast/Disp Ratio:
47.50%
Displacement/Length:
260.35
Comfort Ratio:
19.17
Capsize Screening:
2.00
S-Number:
2.03
Immersion:
96 kg/cm
Notes
The first builder was Bill Stannard of Rhode Island (USA) (23 boats).
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
