PYRAMID 45
Built by Pyramid Boat Works (USA)
• Designed by Chuck Burns
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1983
Dimensions
Length Overall (LOA):
13.72 m
Length Waterline (LWL):
12.19 m
Beam:
3.81 m
Draft (Max):
2.41 m
Weight & Ballast
Displacement:
6,668 kg
Ballast:
3,175 kg
Sail Plan
Foresail Area:
44.22 m²
Mainsail Area:
35.54 m²
Sail Area:
79.76 m²
Sail Area (reported):
79.71 m²
I (Fore Triangle Height):
16.58 m
J (Fore Triangle Base):
5.33 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
5.18 m
Est. Forestay Length:
17.42 m
Engine & Systems
Engine Make:
Isuzu
Engine Type:
Diesel
Engine Model:
3LD1
Fuel Capacity:
189 L
Water Capacity:
341 L
Performance Ratios
Hull Speed:
8.47 knots
SA/Displacement (Calc):
22.97
SA/Displacement (Reported):
22.96
Ballast/Disp Ratio:
47.62%
Displacement/Length:
102.54
Comfort Ratio:
18.94
Capsize Screening:
2.04
S-Number:
5.13
Immersion:
319 kg/cm
