PION 30
Built by Frans Maas/van de Stadt/Friendship Yachts
• Designed by Van de Stadt
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1971
Dimensions
Length Overall (LOA):
9.08 m
Length Waterline (LWL):
7.45 m
Beam:
2.90 m
Draft (Max):
1.92 m
Weight & Ballast
Displacement:
3,650 kg
Ballast:
1,458 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
19.15 m²
Mainsail Area:
16.27 m²
Sail Area:
35.43 m²
Sail Area (reported):
35.40 m²
I (Fore Triangle Height):
10.35 m
J (Fore Triangle Base):
3.70 m
P (Mainsail Hoist):
10.50 m
E (Boom Length):
3.10 m
Est. Forestay Length:
10.99 m
Engine & Systems
Engine Make:
Arona
Engine Type:
Diesel
Performance Ratios
Hull Speed:
6.62 knots
SA/Displacement (Calc):
15.24
SA/Displacement (Reported):
15.23
Ballast/Disp Ratio:
39.94%
Displacement/Length:
246.08
Comfort Ratio:
23.80
Capsize Screening:
1.90
S-Number:
2.04
Immersion:
148 kg/cm
Notes
In 1969, a request from the Royal Dutch Yachting Union was made for a new, offshore one design class.
