PHANTOM 40 (SHEIN)
Built by Phantom Yachts (AUS)
• Designed by Nick Shein
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
First Built:
1988
Last Built:
1997
Dimensions
Length Overall (LOA):
12.30 m
Length Waterline (LWL):
10.30 m
Beam:
3.80 m
Draft (Max):
1.80 m
Headroom:
1.91 m
Weight & Ballast
Displacement:
7,500 kg
Ballast:
2,700 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
64.00 m²
Engine & Systems
Engine Type:
Diesel
Engine Power:
30 HP
Fuel Capacity:
136 L
Water Capacity:
272 L
Performance Ratios
Hull Speed:
7.79 knots
SA/Displacement (Reported):
17.05
Ballast/Disp Ratio:
36.00%
Displacement/Length:
191.28
Comfort Ratio:
24.81
Capsize Screening:
1.96
Immersion:
269 kg/cm
Notes
Winged keel draft: 1.5m / 4.83ft
