PHANTOM 38 (STREUER)
Built by Phantom Yachtbau Genzel (GER)
• Designed by Heribert Streuer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
First Built:
1976
Dimensions
Length Overall (LOA):
12.00 m
Length Waterline (LWL):
9.48 m
Beam:
3.45 m
Draft (Max):
1.70 m
Max Height:
14.05 m
Weight & Ballast
Displacement:
9,500 kg
Ballast:
3,900 kg
Sail Plan
Foresail Area:
33.60 m²
Mainsail Area:
24.99 m²
Sail Area:
58.59 m²
Sail Area (reported):
61.50 m²
I (Fore Triangle Height):
14.00 m
J (Fore Triangle Base):
4.80 m
P (Mainsail Hoist):
12.50 m
E (Boom Length):
4.00 m
Est. Forestay Length:
14.80 m
Engine & Systems
Performance Ratios
Hull Speed:
7.47 knots
SA/Displacement (Calc):
13.33
SA/Displacement (Reported):
13.99
Ballast/Disp Ratio:
41.05%
Displacement/Length:
310.84
Comfort Ratio:
38.06
Capsize Screening:
1.65
S-Number:
1.38
Immersion:
225 kg/cm
Notes
Optional shallow keel draft: 1.5m / 4.92ft
