PACIFIC 38
Built by Smith's Boatyard (NZ)
• Designed by Claude Allen Smith
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1972
Last Built:
1982
Number Built:
45
Dimensions
Length Overall (LOA):
11.50 m
Length Waterline (LWL):
9.29 m
Beam:
3.38 m
Draft (Max):
1.82 m
Headroom:
1.90 m
Weight & Ballast
Displacement:
7,360 kg
Ballast:
3,200 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
31.88 m²
Mainsail Area:
21.74 m²
Sail Area:
53.62 m²
Sail Area (reported):
53.61 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
4.75 m
P (Mainsail Hoist):
11.89 m
E (Boom Length):
3.66 m
Est. Forestay Length:
14.23 m
Engine & Systems
Engine Make:
Bukh
Engine Type:
Diesel
Engine Model:
DV20M
Engine Power:
20 HP
Fuel Capacity:
114 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.40 knots
SA/Displacement (Calc):
14.46
SA/Displacement (Reported):
14.46
Ballast/Disp Ratio:
43.48%
Displacement/Length:
255.81
Comfort Ratio:
31.20
Capsize Screening:
1.75
S-Number:
1.87
Immersion:
215 kg/cm
Notes
Molds were also exported to Australia were an additional 50 hulls were built known as the COMPASS 38. See COMPASS 38.
