OXFORD 400
Built by Oxford Boatyard Co. (USA)
• Designed by Robert G. Henry Jr.
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
First Built:
1946
Dimensions
Length Overall (LOA):
8.79 m
Length Waterline (LWL):
6.86 m
Beam:
2.54 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
3,810 kg
Ballast:
1,724 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
15.58 m²
Mainsail Area:
25.50 m²
Sail Area:
41.09 m²
Sail Area (reported):
41.06 m²
I (Fore Triangle Height):
9.74 m
J (Fore Triangle Base):
3.20 m
P (Mainsail Hoist):
10.97 m
E (Boom Length):
4.65 m
Est. Forestay Length:
10.25 m
Engine & Systems
Engine Make:
Gray
Engine Type:
Gas
Performance Ratios
Hull Speed:
6.36 knots
SA/Displacement (Calc):
17.18
SA/Displacement (Reported):
17.17
Ballast/Disp Ratio:
45.24%
Displacement/Length:
329.22
Comfort Ratio:
31.59
Capsize Screening:
1.64
S-Number:
1.55
Immersion:
120 kg/cm
Notes
Robert Henry was general manager of Oxford Boatyard Co., builder of many boats for the military during WWII.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
