OLYMPIC DOLPHIN 23
Built by Olympic Yachts Ltd.(CAN)
• Designed by Derek Angus
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
First Built:
1973
Dimensions
Length Overall (LOA):
6.93 m
Length Waterline (LWL):
6.25 m
Beam:
2.21 m
Draft (Max):
1.14 m
Draft (Min):
0.51 m
Weight & Ballast
Displacement:
998 kg
Ballast:
454 kg
Sail Plan
Foresail Area:
9.96 m²
Mainsail Area:
9.70 m²
Sail Area:
19.66 m²
Sail Area (reported):
19.60 m²
I (Fore Triangle Height):
7.62 m
J (Fore Triangle Base):
2.62 m
P (Mainsail Hoist):
6.53 m
E (Boom Length):
2.97 m
Est. Forestay Length:
8.06 m
Engine & Systems
Performance Ratios
Hull Speed:
6.07 knots
SA/Displacement (Calc):
20.07
SA/Displacement (Reported):
20.01
Ballast/Disp Ratio:
45.45%
Displacement/Length:
114.00
Comfort Ratio:
11.47
Capsize Screening:
2.23
S-Number:
4.44
Immersion:
95 kg/cm
Notes
Fin keel version: Draft 3.5'/.98m; displacement 2,000 lbs; ballast 800lbs
