NORTH AMERICAN 23
Built by Glastron/North American Yachts
• Designed by Robert Finch
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1976
Last Built:
1978
Dimensions
Length Overall (LOA):
7.01 m
Length Waterline (LWL):
6.10 m
Beam:
2.41 m
Draft (Max):
1.52 m
Draft (Min):
0.61 m
Weight & Ballast
Displacement:
1,270 kg
Ballast:
363 kg
Sail Plan
Foresail Area:
10.07 m²
Mainsail Area:
9.93 m²
Sail Area:
20.00 m²
Sail Area (reported):
19.97 m²
I (Fore Triangle Height):
7.62 m
J (Fore Triangle Base):
2.64 m
P (Mainsail Hoist):
6.86 m
E (Boom Length):
2.90 m
Est. Forestay Length:
8.07 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calc):
17.38
SA/Displacement (Reported):
17.36
Ballast/Disp Ratio:
28.57%
Displacement/Length:
156.25
Comfort Ratio:
13.15
Capsize Screening:
2.25
S-Number:
3.33
Immersion:
101 kg/cm
Notes
North American Yachts was a division of Glastron, one of the largest builders of powerboats in the US.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
