NOR'SEA 27
Built by Heritage Marine
• Designed by Lyle C. Hess
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Masthead Sloop
First Built:
1976
Number Built:
450
Dimensions
Length Overall (LOA):
8.23 m
Length Waterline (LWL):
7.01 m
Beam:
2.44 m
Draft (Max):
1.07 m
Headroom:
1.83 m
Max Height:
10.52 m
Weight & Ballast
Displacement:
3,674 kg
Ballast:
1,406 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
17.13 m²
Mainsail Area:
16.88 m²
Sail Area:
34.01 m²
Sail Area (reported):
34.93 m²
I (Fore Triangle Height):
8.99 m
J (Fore Triangle Base):
3.81 m
P (Mainsail Hoist):
9.39 m
E (Boom Length):
3.60 m
Est. Forestay Length:
9.77 m
Engine & Systems
Engine Make:
Farrymann
Engine Type:
Diesel
Engine Power:
9 HP
Fuel Capacity:
102 L
Water Capacity:
189 L
Performance Ratios
Hull Speed:
6.43 knots
SA/Displacement (Calc):
14.57
SA/Displacement (Reported):
14.96
Ballast/Disp Ratio:
38.27%
Displacement/Length:
297.20
Comfort Ratio:
32.41
Capsize Screening:
1.60
S-Number:
1.57
Immersion:
117 kg/cm
Notes
Available with tall rig (34.5'; 376 sq.ft.) and short (30.5'; 335 sf). Standard (2500 lbs.) and heavy (3000 lbs.) ballast packages were available in the early boats. After 1980, all boats were made with 3100 lbs.' ballast.
