NIMROD 18 (WESTERLY)
Built by Westerly Marine Ltd./Anglo Marine (UK)
• Designed by Ian Proctor
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
First Built:
1968
Last Built:
1978
Number Built:
230
Dimensions
Length Overall (LOA):
5.41 m
Length Waterline (LWL):
4.72 m
Beam:
1.98 m
Draft (Max):
1.22 m
Draft (Min):
0.20 m
Weight & Ballast
Displacement:
476 kg
Ballast:
118 kg
Sail Plan
Sail Area (reported):
13.01 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.28 knots
SA/Displacement (Reported):
21.72
Ballast/Disp Ratio:
24.76%
Displacement/Length:
125.88
Comfort Ratio:
8.28
Capsize Screening:
2.56
Immersion:
64 kg/cm
Notes
Fin keel and twin keel models also available. (186 hulls from Westerly Marine. It is thought that as many as 40 more were built after 1978 by at least 2 other builders from the same tooling.)
