NATIONAL ONE-DESIGN
Built by Ray Greene & Co.
• Designed by William F. Crosby
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Centerboard Dinghy
Rigging Type:
Fractional Sloop
First Built:
1936
Number Built:
1000
Dimensions
Length Overall (LOA):
5.18 m
Length Waterline (LWL):
3.20 m
Beam:
1.73 m
Draft (Max):
1.07 m
Draft (Min):
0.05 m
Weight & Ballast
Displacement:
181 kg
Sail Plan
Sail Area (reported):
12.73 m²
Engine & Systems
Performance Ratios
Hull Speed:
4.34 knots
SA/Displacement (Reported):
40.43
Displacement/Length:
154.26
Comfort Ratio:
4.92
Capsize Screening:
3.08
Immersion:
38 kg/cm
Notes
Plans first appeared in the January 1937 issue of 'The Rudder' magazine. The designer was editor at the Time. Specifications are controlled by National One Design Racing Association, which owns the design. Boats in various stages of completion, parts, and original plans for wood construction are available through the National One-Design Racing Association .
