NASH 26
Built by J. J. Nash Industries (CAN)
• Designed by Joe Nash
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
First Built:
1975
Dimensions
Length Overall (LOA):
7.92 m
Length Waterline (LWL):
6.48 m
Beam:
2.59 m
Draft (Max):
1.17 m
Weight & Ballast
Displacement:
2,359 kg
Ballast:
953 kg
Sail Plan
Foresail Area:
15.10 m²
Mainsail Area:
11.65 m²
Sail Area:
26.74 m²
Sail Area (reported):
26.76 m²
I (Fore Triangle Height):
9.53 m
J (Fore Triangle Base):
3.17 m
P (Mainsail Hoist):
8.99 m
E (Boom Length):
2.59 m
Est. Forestay Length:
10.04 m
Engine & Systems
Performance Ratios
Hull Speed:
6.18 knots
SA/Displacement (Calc):
15.39
SA/Displacement (Reported):
15.40
Ballast/Disp Ratio:
40.38%
Displacement/Length:
241.92
Comfort Ratio:
20.48
Capsize Screening:
1.97
S-Number:
2.09
Immersion:
115 kg/cm
Notes
The builder was located at Strathroy, Ontario, CANADA.
