NAJAD 520
Built by Najad Varvet AB
• Designed by Carl Beyer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1994
Last Built:
2001
Dimensions
Length Overall (LOA):
15.80 m
Length Waterline (LWL):
13.55 m
Beam:
4.60 m
Draft (Max):
2.20 m
Weight & Ballast
Displacement:
20,000 kg
Ballast:
6,800 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
56.19 m²
Mainsail Area:
52.07 m²
Sail Area:
108.26 m²
Sail Area (reported):
108.23 m²
I (Fore Triangle Height):
19.55 m
J (Fore Triangle Base):
5.75 m
P (Mainsail Hoist):
17.36 m
E (Boom Length):
6.00 m
Est. Forestay Length:
20.38 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
4LH-HTE
Engine Power:
135 HP
Fuel Capacity:
689 L
Water Capacity:
999 L
Performance Ratios
Hull Speed:
8.93 knots
SA/Displacement (Calc):
15.00
SA/Displacement (Reported):
15.00
Ballast/Disp Ratio:
34.00%
Displacement/Length:
224.13
Comfort Ratio:
39.34
Capsize Screening:
1.71
S-Number:
2.21
Immersion:
428 kg/cm
Notes
A DS (deck salon) version was also available.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
