NAJAD 343
Built by Najad Varvet AB
• Designed by Thorwald Karlsson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1981
Last Built:
1989
Dimensions
Length Overall (LOA):
10.20 m
Length Waterline (LWL):
8.70 m
Beam:
3.33 m
Draft (Max):
1.65 m
Weight & Ballast
Displacement:
6,500 kg
Ballast:
2,500 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
22.69 m²
Mainsail Area:
24.11 m²
Sail Area:
46.80 m²
Sail Area (reported):
49.98 m²
I (Fore Triangle Height):
12.60 m
J (Fore Triangle Base):
3.60 m
P (Mainsail Hoist):
11.10 m
E (Boom Length):
4.34 m
Est. Forestay Length:
13.10 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD17D
Engine Power:
43 HP
Fuel Capacity:
201 L
Water Capacity:
201 L
Performance Ratios
Hull Speed:
7.16 knots
SA/Displacement (Calc):
13.71
SA/Displacement (Reported):
14.64
Ballast/Disp Ratio:
38.46%
Displacement/Length:
275.19
Comfort Ratio:
30.52
Capsize Screening:
1.80
S-Number:
1.65
Immersion:
199 kg/cm
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
