MUMM 36
Built by Carroll Marine (license)
• Designed by Bruce Farr
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
1993
Number Built:
120
Dimensions
Length Overall (LOA):
10.92 m
Length Waterline (LWL):
9.68 m
Beam:
3.61 m
Draft (Max):
2.23 m
Weight & Ballast
Displacement:
3,697 kg
Ballast:
1,588 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
25.58 m²
Mainsail Area:
34.26 m²
Sail Area:
59.84 m²
Sail Area (reported):
59.83 m²
I (Fore Triangle Height):
13.32 m
J (Fore Triangle Base):
3.84 m
P (Mainsail Hoist):
13.62 m
E (Boom Length):
5.03 m
SPL/TPS:
3.84 m
ISP:
13.32 m
Est. Forestay Length:
13.86 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20FC-SD20
Engine Power:
18 HP
Fuel Capacity:
45 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
7.55 knots
SA/Displacement (Calc):
25.53
SA/Displacement (Reported):
25.53
Ballast/Disp Ratio:
42.94%
Displacement/Length:
113.68
Comfort Ratio:
14.22
Capsize Screening:
2.36
S-Number:
5.24
Immersion:
240 kg/cm
Notes
Originally (first 6) called FARR 36.
