MORGAN 45 (CATALINA)
Built by Catalina Yachts (USA)
• Designed by Nelson Marek
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
First Built:
1991
Dimensions
Length Overall (LOA):
13.79 m
Length Waterline (LWL):
11.53 m
Beam:
4.19 m
Draft (Max):
1.62 m
Weight & Ballast
Displacement:
11,340 kg
Ballast:
3,765 kg
Sail Plan
Foresail Area:
41.66 m²
Mainsail Area:
34.19 m²
Sail Area:
75.84 m²
Sail Area (reported):
75.81 m²
I (Fore Triangle Height):
16.08 m
J (Fore Triangle Base):
5.18 m
P (Mainsail Hoist):
14.02 m
E (Boom Length):
4.88 m
Est. Forestay Length:
16.89 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
50 HP
Performance Ratios
Hull Speed:
8.24 knots
SA/Displacement (Calc):
15.34
SA/Displacement (Reported):
15.33
Ballast/Disp Ratio:
33.20%
Displacement/Length:
206.15
Comfort Ratio:
29.40
Capsize Screening:
1.88
S-Number:
2.44
Immersion:
332 kg/cm
Notes
Deep Keel version also available. Draft: 6.58ft.; Displacement: 25,450; Ballast: 8300 lbs.
