MORGAN 36T
Built by Morgan Yachts (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1973
Dimensions
Length Overall (LOA):
10.90 m
Length Waterline (LWL):
9.14 m
Beam:
3.58 m
Draft (Max):
1.91 m
Max Height:
15.87 m
Weight & Ballast
Displacement:
6,350 kg
Ballast:
2,767 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
33.45 m²
Mainsail Area:
24.68 m²
Sail Area:
58.12 m²
Sail Area (reported):
58.16 m²
I (Fore Triangle Height):
14.63 m
J (Fore Triangle Base):
4.57 m
P (Mainsail Hoist):
12.95 m
E (Boom Length):
3.81 m
Est. Forestay Length:
15.33 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
68 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.34 knots
SA/Displacement (Calc):
17.29
SA/Displacement (Reported):
17.30
Ballast/Disp Ratio:
43.57%
Displacement/Length:
231.48
Comfort Ratio:
25.62
Capsize Screening:
1.95
S-Number:
2.39
Immersion:
225 kg/cm
Notes
Also called MORGAN 1 TON. Not to be confused with the a later HERITAGE ONE TON which is an entirely different design. (The IOR rating for one ton level racing was changed from 27.5 to 30.5 in 1984.)
