MORGAN 35
Built by Morgan Yachts (USA)
• Designed by Charles Morgan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/CB & spade rudder
Rigging Type:
Masthead Sloop
First Built:
1970
Number Built:
140
Dimensions
Length Overall (LOA):
10.67 m
Length Waterline (LWL):
8.41 m
Beam:
3.28 m
Draft (Max):
2.06 m
Draft (Min):
1.30 m
Max Height:
13.56 m
Weight & Ballast
Displacement:
5,398 kg
Ballast:
2,268 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
25.88 m²
Mainsail Area:
24.96 m²
Sail Area:
50.83 m²
Sail Area (reported):
50.82 m²
I (Fore Triangle Height):
12.42 m
J (Fore Triangle Base):
4.17 m
P (Mainsail Hoist):
10.92 m
E (Boom Length):
4.57 m
Est. Forestay Length:
13.10 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
98 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
7.04 knots
SA/Displacement (Calc):
16.86
SA/Displacement (Reported):
16.85
Ballast/Disp Ratio:
42.02%
Displacement/Length:
253.23
Comfort Ratio:
26.09
Capsize Screening:
1.89
S-Number:
2.13
Immersion:
189 kg/cm
Notes
Westerbeke 4-107 diesel offered as an option.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
