MOODY 41 DS
Built by Moody/HanseYachts AG
• Designed by Dixon Yacht Design
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2019
Dimensions
Length Overall (LOA):
12.52 m
Length Waterline (LWL):
11.42 m
Beam:
4.20 m
Draft (Max):
2.14 m
Max Height:
19.92 m
Weight & Ballast
Displacement:
11,200 kg
Ballast:
3,130 kg
Ballast Type:
Cast iron
Sail Plan
Foresail Area:
39.48 m²
Mainsail Area:
44.54 m²
Sail Area:
84.02 m²
Sail Area (reported):
83.00 m²
I (Fore Triangle Height):
16.80 m
J (Fore Triangle Base):
4.70 m
P (Mainsail Hoist):
16.20 m
E (Boom Length):
5.50 m
Est. Forestay Length:
17.45 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
57 HP
Fuel Capacity:
210 L
Water Capacity:
475 L
Performance Ratios
Hull Speed:
8.20 knots
SA/Displacement (Calc):
17.13
SA/Displacement (Reported):
16.92
Ballast/Disp Ratio:
27.94%
Displacement/Length:
209.54
Comfort Ratio:
30.09
Capsize Screening:
1.90
S-Number:
2.61
Immersion:
329 kg/cm
Notes
Shallow keel option: draft - 1.83m / 6.0 ft
