MOODY 34
Built by Marine Projects Ltd.
• Designed by Bill Dixon
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1983
Last Built:
1986
Number Built:
165
Dimensions
Length Overall (LOA):
10.19 m
Length Waterline (LWL):
8.46 m
Beam:
3.56 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
5,080 kg
Ballast:
2,041 kg
Sail Plan
Foresail Area:
26.35 m²
Mainsail Area:
21.74 m²
Sail Area:
48.09 m²
Sail Area (reported):
48.12 m²
I (Fore Triangle Height):
12.65 m
J (Fore Triangle Base):
4.17 m
P (Mainsail Hoist):
10.97 m
E (Boom Length):
3.96 m
Est. Forestay Length:
13.32 m
Engine & Systems
Engine Make:
Thornycroft T90 35hp or Volvo 2003 28hp diesel
Engine Type:
Diesel
Fuel Capacity:
159 L
Water Capacity:
182 L
Performance Ratios
Hull Speed:
7.06 knots
SA/Displacement (Calc):
16.60
SA/Displacement (Reported):
16.61
Ballast/Disp Ratio:
40.18%
Displacement/Length:
233.98
Comfort Ratio:
22.28
Capsize Screening:
2.09
S-Number:
2.29
Immersion:
207 kg/cm
Notes
Bilge Keel version - draft: 3.75'
