MONTEGO 20
Built by Universal Marine Corp. (USA)
• Designed by Johannes Helsen
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
First Built:
1976
Last Built:
1985
Dimensions
Length Overall (LOA):
5.94 m
Length Waterline (LWL):
5.41 m
Beam:
2.19 m
Draft (Max):
0.61 m
Weight & Ballast
Displacement:
771 kg
Ballast:
272 kg
Sail Plan
Foresail Area:
7.12 m²
Mainsail Area:
8.29 m²
Sail Area:
15.41 m²
Sail Area (reported):
17.56 m²
I (Fore Triangle Height):
6.40 m
J (Fore Triangle Base):
2.23 m
P (Mainsail Hoist):
6.40 m
E (Boom Length):
2.59 m
Est. Forestay Length:
6.78 m
Engine & Systems
Performance Ratios
Hull Speed:
5.65 knots
SA/Displacement (Calc):
18.68
SA/Displacement (Reported):
21.28
Ballast/Disp Ratio:
35.29%
Displacement/Length:
135.71
Comfort Ratio:
10.42
Capsize Screening:
2.41
S-Number:
3.84
Immersion:
81 kg/cm
Notes
The MONTEGO 19 and 20 share the same hull but with different keel configrations. (The 19 is fitted with a Swing Keel). Later it became the SOVEREIGN 20.
