MIRAGE 24
Built by Mirage Yachts Ltd. (CAN)
• Designed by Cuthbertson & Cassian
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
First Built:
1972
Dimensions
Length Overall (LOA):
7.26 m
Length Waterline (LWL):
6.12 m
Beam:
2.57 m
Draft (Max):
1.22 m
Weight & Ballast
Displacement:
1,678 kg
Ballast:
680 kg
Sail Plan
Foresail Area:
11.71 m²
Mainsail Area:
8.98 m²
Sail Area:
20.69 m²
Sail Area (reported):
20.72 m²
I (Fore Triangle Height):
8.53 m
J (Fore Triangle Base):
2.74 m
P (Mainsail Hoist):
7.10 m
E (Boom Length):
2.53 m
Est. Forestay Length:
8.96 m
Engine & Systems
Performance Ratios
Hull Speed:
6.00 knots
SA/Displacement (Calc):
14.94
SA/Displacement (Reported):
14.96
Ballast/Disp Ratio:
40.54%
Displacement/Length:
204.02
Comfort Ratio:
15.78
Capsize Screening:
2.18
S-Number:
2.41
Immersion:
108 kg/cm
Notes
Nearly the same as the NORTHERN 1/4 TON though originally designed to compete under the MORC rule.
