MG RS34
Built by Marine Glass (UK)
• Designed by Rob Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1983
Number Built:
15
Dimensions
Length Overall (LOA):
10.36 m
Length Waterline (LWL):
9.00 m
Beam:
3.41 m
Draft (Max):
1.98 m
Weight & Ballast
Displacement:
3,561 kg
Ballast:
1,120 kg
Sail Plan
Foresail Area:
19.78 m²
Mainsail Area:
30.29 m²
Sail Area:
50.07 m²
Sail Area (reported):
53.88 m²
I (Fore Triangle Height):
11.80 m
J (Fore Triangle Base):
3.35 m
P (Mainsail Hoist):
12.82 m
E (Boom Length):
4.72 m
Est. Forestay Length:
12.27 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20
Performance Ratios
Hull Speed:
7.28 knots
SA/Displacement (Calc):
21.90
SA/Displacement (Reported):
23.57
Ballast/Disp Ratio:
31.46%
Displacement/Length:
136.09
Comfort Ratio:
15.74
Capsize Screening:
2.26
S-Number:
4.29
Immersion:
211 kg/cm
Notes
Based on an IOR 3/4 ton design 'Roller Skate' (1982). (Prototype was 'Seren Wib')
