MAYFLOWER 48/STADEL 48
Built by Mayflower Boatyards (Taiwan)
• Designed by George Stadel Jr.
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Ketch
First Built:
1979
Last Built:
1984
Number Built:
42
Dimensions
Length Overall (LOA):
14.63 m
Length Waterline (LWL):
11.94 m
Beam:
4.11 m
Draft (Max):
1.73 m
Weight & Ballast
Displacement:
16,783 kg
Ballast:
5,670 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
42.61 m²
Mainsail Area:
36.42 m²
Sail Area:
79.02 m²
Sail Area (reported):
98.01 m²
I (Fore Triangle Height):
16.37 m
J (Fore Triangle Base):
5.21 m
P (Mainsail Hoist):
14.94 m
E (Boom Length):
4.88 m
PY (Mizzen Hoist):
10.80 m
EY (Mizzen Boom):
3.56 m
Est. Forestay Length:
17.18 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4-236
Engine Power:
85 HP
Performance Ratios
Hull Speed:
8.39 knots
SA/Displacement (Calc):
12.31
SA/Displacement (Reported):
15.27
Ballast/Disp Ratio:
33.78%
Displacement/Length:
274.85
Comfort Ratio:
42.71
Capsize Screening:
1.62
S-Number:
1.50
Immersion:
337 kg/cm
Notes
The boats were fitted with either Ford or Perkins diesels. One of several models sold based on this particular hull.
