MARSHALL 22 CAT
Built by The Marshall Company (USA)
• Designed by Breckenridge Marshall
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Gaff head Cat
First Built:
1965
Dimensions
Length Overall (LOA):
6.76 m
Length Waterline (LWL):
6.50 m
Beam:
3.10 m
Draft (Max):
1.58 m
Draft (Min):
0.61 m
Weight & Ballast
Displacement:
2,567 kg
Ballast:
386 kg
Sail Plan
Sail Area (reported):
36.05 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3YM20
Engine Power:
21 HP
Fuel Capacity:
45 L
Water Capacity:
83 L
Performance Ratios
Hull Speed:
6.19 knots
SA/Displacement (Reported):
19.61
Ballast/Disp Ratio:
15.02%
Displacement/Length:
260.37
Comfort Ratio:
18.43
Capsize Screening:
2.29
Immersion:
139 kg/cm
Notes
A sloop rigged version was also available. See MARSHALL 22 SLOOP.
