MARINER 40 (GARDEN)
Built by Far East Yacht Builders, Inc - Ta Yang
• Designed by C. Oberly/W. Garden
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Ketch
First Built:
1965
Dimensions
Length Overall (LOA):
12.29 m
Length Waterline (LWL):
9.20 m
Beam:
3.48 m
Draft (Max):
1.73 m
Weight & Ballast
Displacement:
12,020 kg
Ballast:
4,082 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
35.12 m²
Mainsail Area:
29.57 m²
Sail Area:
64.70 m²
Sail Area (reported):
68.10 m²
I (Fore Triangle Height):
14.71 m
J (Fore Triangle Base):
4.78 m
P (Mainsail Hoist):
12.73 m
E (Boom Length):
4.65 m
PY (Mizzen Hoist):
8.00 m
EY (Mizzen Boom):
3.30 m
Est. Forestay Length:
15.46 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Fuel Capacity:
284 L
Water Capacity:
454 L
Performance Ratios
Hull Speed:
7.36 knots
SA/Displacement (Calc):
12.59
SA/Displacement (Reported):
13.25
Ballast/Disp Ratio:
33.96%
Displacement/Length:
430.80
Comfort Ratio:
48.11
Capsize Screening:
1.54
S-Number:
0.78
Immersion:
220 kg/cm
Notes
The earliest version of the MARINER 40 was built of wood in 1965 and then later in fiberglass with wood decks and superstructure. Far East Yachts built the boats, first in Japan (95 hulls) and then in California. Later the molds for the MARINER 40 and MARINER 36 were purchased by another company and construction continued for some years at the Ta-Yang yard in Taiwan.
