MAPLE LEAF ONE-DESIGN
Built by Plywood Fabricators Ltd. (CAN)
• Designed by Sparkman & Stephens
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
First Built:
1946
Dimensions
Length Overall (LOA):
10.72 m
Length Waterline (LWL):
7.32 m
Beam:
2.39 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
4,536 kg
Sail Plan
Foresail Area:
18.37 m²
Mainsail Area:
29.99 m²
Sail Area:
48.36 m²
Sail Area (reported):
49.24 m²
I (Fore Triangle Height):
10.30 m
J (Fore Triangle Base):
3.57 m
P (Mainsail Hoist):
11.64 m
E (Boom Length):
5.15 m
Est. Forestay Length:
10.90 m
Engine & Systems
Engine Make:
Gray
Engine Type:
Gas
Performance Ratios
Hull Speed:
6.56 knots
SA/Displacement (Calc):
18.00
SA/Displacement (Reported):
18.33
Displacement/Length:
322.94
Comfort Ratio:
36.43
Capsize Screening:
1.46
S-Number:
1.65
Immersion:
120 kg/cm
Notes
S&S design #730. Commissioned by the Royal Canadian YC of Toronto for which the first six were built in 1947.
